Aluminium Cap Closer IMA ALU 400 |
|
 |
This machine is designed to seal Aluminium Caps with very low particles generation and is therefore ...
Quick
| Detailed
Description
This machine is designed to seal Aluminium Caps with very low particles generation and is therefore suitable for aseptic conditions in Clean Rooms and under Isolators.
Cap sealing is carried out with an idle edging roller and by rotation of the container support plates.
The machine comprises of a stainless steel cabinet which supports the closing station as well as a 350 cm long PVC slat conveyor.
The machine is controlled via a Siemens OP 17 Operating Panel.
The design parameters of this machine are as follows:
Bottle diameter: min. 14 mm - max. 52 m
Bottle height: min. 35 mm - max. 110 mm
Cap diameter: min. 13 mm - max. 40 mm
Cap height: min. 6 mm - max. 16 mm
Capacity: max. 24.000 bottles/hr.
Manufacturer: IMA / Italy
Click on the Add to Enquiry List Button to request a full Description and Quotation
|
|
|
Cream Manufacturing Plant FRYMA VME 120 |
|
 |
This Cream Processing Plant is suitable for the production of emulsions, creams, pastes, suppository...
Quick
| Detailed
Description
This Cream Processing Plant is suitable for the production of emulsions, creams, pastes, suppository masses etc. and has a batch capacity of 120 litres. The total volume is 200 litres and the minimum practicable batch size is 50 litres.
The plant comprises a double-jacketed stainless steel mixing pan. The jacket is suitable for heating using steam or water (hot or cold) at a maximum pressure of 3 bar. The lid is lowered and raised hydraulically and the pan can then be tilted for discharge. Alternatively the finished product can be discharged through a centre bottom outlet.
The lid supports the following mixing tools:
Anchor Stirrer with side scrapers
Dissolver disc
Homogeniser with Toothed Colloid Mill
The Machine Body houses the Hydraulic Aggregate, Liquid Ring Vacuum Pump, the relevant pipe connections and the electrical Installation.
Manufacturer: Fryma, Rheinfelden / Switzerland
Click on the Add to Enquiry List Button to request a full Description and Quotation
|
|
|
Stretchbander BFB MS 500 E with Shrink Tunnel |
|
 |
This is a fully automatic packaging machine comprising an infeed conveyor, collation station for mul...
Quick
| Detailed
Description
This is a fully automatic packaging machine comprising an infeed conveyor, collation station for multi-layer collations, stretch-banding station and heat shrink tunnel.
The infeed conveyor and collation station has adjustable guides to suit different pack or collation sizes. Stretch film is supplied from the top and bottom of the machine where 2 reels rest on adjustable rollers.
The machine is electronically (PLC) controlled - operation parameters are entered via a soft-touch control panel with digital display.
The manufacturers state an output capacity of up to 30 items/collations per minute.
Manufacturer: IMA BFB, Italy
Electrical Spec: 415 V, 3 Ph, 50 Hz
Click on the Add to Enquiry List Button to request a full Description and Quotation
|
|
Well maintained used pharmaceutical machines and pharmaceutical packaging machinery are often a viable alternative to new equipment with high costs and long delivery times.
Pharma Machines Ltd have been suppliers of used Pharmaceutical Machines and Pharmaceutical Packaging Machinery since 1975. We supply a wide range of Pharmaceutical machines from process and manufacturing to packaging machinery. These range from laboratory size to production scale.
We are proud to have been suppliers of pharmaceutical machines to the Pharmaceutical Industry world-wide from our premises in London, UK for more than 30 years.
In our works in London, UK we exhibit used pharmaceutical machines for processing and manufacturing and also pharmaceutical packaging machinery. The majority of these machines can be seen running and we can often demonstrate machines with customer’s product or packaging materials.
